MPO 16F Pull Boot Connector

The newly released MPO 16F Pull Boot Connector takes our proven technology into a high fiber count option. The 16F design has the standard off-center key position and is available in 2 boot styles and 2 cable sizes (3.0mm and 3.5mm).


  • Designed with industry standard off-center key position
  • Created for high-density packaging
  • Available in 2 boot options
  • Now available in a Short Pull Boot


Fiber Type: 16 Fibers, 32 Fibers

Application Mode: SM, MM, Low Loss SM, Low Loss MM

Insertion Loss: SL 0.35dB/SM 0.7dB/ML 0.35dB/MM 0.6dB

Return Loss: SL 60dB (8°polish)/SM 60dB (8°polish)/ ML 20dB (flat polish/MM 20dB (flat polish)

– IEC-61754-7 and TIA-604-5-D
